Description
Main Features:
Low RPM
High torque
Fully automated production
Optional sizes for different use
MODEL
VOLTAGE
NO-LOAD SPEED
RATED TORQUE
POWER
STALL TORQUE
RATED CURREN
MA5840GF555SH
6-12V
470-16RPM
5-70kgf.cm
20W
17-70kgf.cm
1.6A
MA5840GF555SH
12-24 V
470-16RPM
6.8-70kgf.cm
28W
17-70kgf.cm
2.0A
Voltage, shaft, gearbox size can be customized to meet various performance data.
About us:
Shanghai Meichu Industrial Co., Ltd. is a professional supplier of various micro motors as well as motor related products more than 10 years.Our products includes various DC motors, gear motors, AC motors, fan motors and electric actuators etc...
We also offer solution of transmission design, structrual design and product development plan. We are good at making both standard and non-standard micro motors. Our motors are widely used in cars, home appliance, medical device, dental equipment, robotics, smart products,electricl equipment, sports apparatus,conveying machinery etc..
Our products meet the standards of CE, ISO 9001, UL, REACH, RoHS,ETL and SGS.
We pay close attention to technology, quality,standardization and process management.
We always operate in brand thinking way and take addressing customer pain points as our responsibility.
"First Responsibility Then Business. "is our unchanged commitment.
